‏נקודת גישה Aruba R4W05A Instant On AP22 HP

Radios
Dual radio for simultaneous dual-band operation
5 GHz 802.11ax 2x2 MIMO for up to 1.2Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)
Maximum (aggregate, Conducted Total) Transmit Power (limited By Local Regulatory Requirements)
5GHz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
2.4Ghz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
Interfaces
Uplink Gigabit Ethernet port, with PoE-in support (802.3af)
DC power connector (12V) Bluetooth Low Energy (BLE) radio LED status indicators (2) Reset/LED control button Kensington security slot
Physical Specifications
160mm x 160mm x 37mm, excluding mount accessories
Weight: 500g
Power
Power over Ethernet (POE): 802.3af (class 3)
Max power consumption (worst-case): 10.1W (PoE), 8.8W (DC) DC power (12V)
Note: Power sources are sold separately unless you purchase the bundle SKU which comes with power options.
Antennas
Down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 4.3dBi in 2.4GHz and 5.6dBi in 5GHz (of the effective, combined pattern for both antennas in each band).
Mounting
The access point ships with a white mount clip that can attach to both wall and ceiling. You can also purchase a mount (R6P90A) for aesthetic design and looks of the APs, to blend seamless into your environment
Industry Certifications
UL 2043 plenum rating
EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments)
Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3
Management Options
Instant On mobile application (Android & iOS)
Cloud Portal: Portal.ArubaInstantOn.com

Environmental & Reliability
Operating temperature: 0° C to +40° C
(+32° F to +104° F)
MTBF: 795khrs (91yrs) at +25° C
