CPUIntel® Celeron® J6412 4-core/4-thread processor, burst up to 2.6 GHz
CPU Architecture64-bit x86
Graphic ProcessorsIntel® UHD Graphics
Floating Point Unit✓
Encryption Engine✓ (AES-NI)
Hardware-accelerated Transcoding✓
System Memory8 GB on board (non-expandable)
Maximum Memory8GB
Flash Memory4GB (Dual boot OS protection)
Drive Bay4x 3.5-inch SATA 6Gb/s
The system is shipped without HDD.
For the HDD compatibility list, please visit
https://www.qnap.com/compatibility/Drive Compatibility3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable✓
M.2 Slot2x M.2 2280 PCIe Gen 3 x2
SSD Cache Acceleration Support✓
2.5 Gigabit Ethernet Port (2.5G/1G/100M)2 (2.5G/1G/100M/10M)
Wake on LAN (WOL)✓
Jumbo Frame✓
USB 2.0 port2
USB 3.2 Gen 2 (10Gbps) Port2x Type-A
HDMI Output2x HDMI 1.4b ( up to 3840 x 2160 @ 30Hz )
Form FactorTower
LED IndicatorsPower/Status, LAN, USB, HDD1-4
ButtonsPower, Reset, USB Auto Copy
Dimensions (HxWxD)177x180x235 mm
Weight (Net)3 kg
Weight (Gross)4.3 kg
Operating Temperature0 - 40 °C (32°F - 104°F)
Storage Temperature-20 - 70°C (-4°F - 158°F)
Relative Humidity5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit90W adapter, 100-240V
Power Consumption: HDD Sleep Mode15.78 W
Power Consumption: Operating Mode, Typical33.88 W
Fan1x 120mm, 12VDC
System WarningBuzzer
Kensington Security Slot✓
Max. Number of Concurrent Connections (CIFS) - with Max. Memory1500
Note
Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
