Power Supply
Built-in power supply
Voltage Range
Ac100~ 240V
Consumption
Speed
1-24 Port: 10/100/1000Mbps
Transmission Distance
100Meter (328ft)
Ethernet Standard
IEEE 802.3/802.3u / 802.3ab
Switching capacity
48G
MACAddress
8K MAC address table
Dimension L* W * H
270 x 180 x 44mm
VLAN (1-22Ports) - Port Isolation
Downlink designated ports are isolated from each other, only transmit data with the uplink port.
Default Standard Switch
All ports communicate freely
Extend (1-22Ports) Link Extension
The specified port speed drops to 10Mbps, max transmission distance is 250 meters.
LINK/ACT
On Green
The port is connecting
Blinks /
The port is receiving or transmitting data
Off /
The port is not linked successfully with the device
Transfer Rate
14,880 pps for 10Mbps
148,800 pps for 100Mbps
148,8000 pps for 100Mbps
Environment
Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~70℃
Operating Humidity: 10%~85% non-condensing
Storage humidity: 5%~85% non-condensing
