נקודת גישה Aruba HPE S1U79A AP22D

CertificationsWi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Input voltagePoE: 802.3bt (class 6) Full functionality or 802.3at (class 4) limited functionality DC power (48V)
PoE In: 802.3at/802.3bt
POE Out: 2x 15W PoE (802.3af)

Note: Power sources are sold separately unless you purchase the bundle SKU

Wi-Fi antennaAntennas: Dual semi-directional 2x2 MIMO
Antenna Gain: 5.2 dBi in 2.4GHz and 5.4 dBi in 5 GHz
Maximum transmit power:
5 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)
2.4 GHz band: +20 dBm (+17 dBm per chain, 3 dB MIMO gain)

Connectivity, standardUltra-fast 802.11ax

Ports1x 2.5 GbE Base-T PoE Class 4/6 uplink
2x 1 GbE Base-T PoE Class 3 downlink
2x 1 GbE Base-T downlink
DC power connector
LED status indicators
Reset/LED control button
Kensington security slot

MountingGang wall box-mount kit or Desk-mount kit

Power consumption51W (PoE) or 50W (DC)

Radio coverageDual-radio 802.11ax
2x2 5 GHz/2.4 GHz MIMO

WarrantyInstant On 2-year warranty includes 24X7 phone support for the first 90 days and chat support for the entire warranty period.
Community support is available for the life of the product.

Detailed product descriptionThe HPE Networking Instant On Access Points AP22D is the more versatile version of the AP22. It has the same antenna array and spatial streams (2x2:2) but has a 2.5 GbE uplink port and four 1 GbE downlink ports for hardwired devices. The AP22D is great for IP phones or receipt printers in areas that need more Ethernet ports and only one in-room Ethernet port is available.

DifferentiatorIn the Box:
HPE Networking Instant On Access Point
Quick Start guide
Combined ceiling and wall rail mount clip
Ethernet cable
Desktop mount

Add PoE or DC power source
