| Model Variations |
With FlexStand, Without Stand |
| Cabinet Color |
Black |
| Panel |
|
| Type |
IPS |
| Backlight |
LED |
| Size |
26.5" / 67 cm |
| Native Resolution |
1920 x 1920 (1:1 aspect ratio) |
| Viewable Image Size (H x V) |
475.7 x 475.7 mm |
| Pixel Pitch |
0.248 x 0.248 mm |
| Display Colors |
16.77 million |
| Viewing Angles (H / V, typical) |
178° / 178° |
| Brightness (typical) |
300 cd/m2 |
| Contrast Ratio (typical) |
1000:1 |
| Response Time (typical) |
5 ms (Gray-to-gray) |
| Video Signals |
|
| Input Terminals |
DisplayPort (HDCP 1.3), DVI-D (HDCP 1.4) |
| Digital Scanning Frequency (H / V) |
31 - 127 kHz / 59 - 61 Hz |
| USB |
|
| Upstream |
USB 2.0: Type-B |
| Downstream |
USB 2.0: Type-A x2 |
| Audio |
|
| Speakers |
1.0 W +1.0 W |
| Input Terminals |
3.5 mm stereo jack |
| Output Terminals |
3.5 mm headphone jack |
| Sound Adjustment |
Volume, Power Save, Source (DisplayPort) |
| Power |
|
| Power Requirements |
AC 100 -240 V, 50 / 60 Hz |
| Maximum Power Consumption |
64 W |
| Typical Power Consumption |
25 W |
| Power Save Mode |
0.5 W or less |
| Features & Functions |
|
| Preset Modes |
FineContrast (User1, User2, sRGB, Paper, Movie) |
| Auto EcoView |
Yes |
| EcoView Sense |
Yes |
| OSD Languages |
English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
| Physical Specifications |
|
| Dimensions (Landscape, W x H x D) |
497 x 512.5 - 613.5 x 245 mm |
| Dimensions (Without Stand, W x H x D) |
497 x 501.5 x 56 mm |
| Net Weight |
7.1 kg |
| Net Weight (Without Stand) |
4.2 kg |
| Height Adjustment Range |
101 mm |
| Tilt |
35° Up, 5° Down |
| Swivel |
344° |
| Pivot |
- |
| Hole Spacing (VESA Standard) |
100 x 100 mm |
| Environmental Requirements |
|
| Operating Temperature |
5 - 35 °C |
| Operating Humidity (R.H., non condensing) |
20 - 80 % |
| Certifications & Standards (Please contact EIZO for the latest information.) |
TUV/Ergonomics, TUV/Low blue light content, TUV/Flicker Free, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, VCCI-B, RoHS, WEEE, China RoHS, CCC, EAC |
| Supplied Accessories (May vary by country. Please contact EIZO for details.) |
|
| Signal Cables |
DisplayPort (2 m), Dual Link DVI-D (2 m) |
| Others |
AC power cord (2 m), Screw for VESA mount x4 (EV2730Q-F), EIZO LCD Utility Disk (PDF user's manual, ScreenManager Pro for LCD [DDC/CI], EIZO ScreenSlicer software), setup guide |
