מבצע ₪ 1,750 ILS 8/7/2027 Out of stock https://www.pccenter.co.il/product/אל-פסק-eaton-5p1550i-va-tower Eaton 1012507 1012507
| General | |
| Topology | Line-Interactive High Frequency (Pure Sinewave, Booster + Fader) |
| Configuration | Rack 1U |
| Part Number | 5P1550iR |
| Rating (VA/Watts) | 1550/1100 |
| Dimensions (H x W x D, mm) | 43.2 x 438 x 554 |
| Weight (kg) | 19.4 |
| Warranty | 3 years on electronics, 2 years on batteries |
| Electrical Input | |
| Connection |
(1) IEC-320-C14
 |
| Input Voltage Without Using Batteries | 160V-294V (adjustable to 150V-294V) |
| Input frequency Range Without Using Batteries | 47 to 70Hz (50 Hz system), 56.5 to 70Hz (60 Hz system), 40Hz in low-sensitivity mode |
| Electrical Output | |
| Voltages | 230 V (+6/-10 %) (Adjustable to 200V / 208V / 220V / 230V / 240V) |
| Output Receptacles |
(6) IEC-320-C13
 |
| Remotely controlled sockets | 2 groups of 2 x IEC C13 (10 A) |
| Output Frequency | 50/60 Hz +/- 0.1 % (autosensing) |
| Battery Management | ABM® & temperature compensated charging method (user selectable), automatic battery test, deep discharge protection |
| Communications | |
| Communication Ports | 1 USB port + 1 RS232 serial port and relay contacts (USB and RS232 ports cannot be used simultaneously), 1 mini-terminal block for remote ON/OFF and Remote Power Off |
| Communications Card Slots | 1 slot for Network-MS card, ModBus-MS or Relay-MS cards |
| Environmental & Standards | |
| Audible Noise | < 40 dBA |
| Operating Temperature | 0 to 40°C |
| Safety markings | IEC/EN 62040-1, UL 1778 |
| EMC Markings | IEC/EN 62040-2, IEC/EN 62040-3 (performance) |
| Approvals | CE, CB report, TÜV |
